Specifications
| Stator Diameter |
40 mm (1.56 in) |
| Stator Thickness |
25 mm (0.98 in) |
| No. of Stator Arms |
12 |
| Magnet Poles |
8 |
| Motor Wind |
14 Turn Delta |
| Motor Wire |
18 – Strand 0.29mm |
| Motor Kv |
550KV RPM / Volt |
| No-Load Current (IO) |
0.9 Amps @ 10v |
| Motor Resistance (RM) |
0.035 Ohms |
| Max Continuous Current |
65 Amps |
| Max Continuous Power |
2850 Watts |
| Weight |
326 Grams (11.50 oz) |
| Outside Diameter |
48.9 mm (1.9 in) |
| Shaft Diameter |
5.98 mm (0.235 in) |
| Body Length |
51.5 mm (2.01 in) |
| Overall Shaft Length |
83.7 mm (3.30 in) |
| Max Lipo Cell |
12s |
| Motor Timing |
5deg |
| Drive Frequency |
8kHz |
